bleak impedance matcher

passive impedance matcher

click image to view larger

.\\\\\\\\' DESCRIPTION .\\\\\\\\\\\\\\\\\\\\\\\'

this is a passive transformer based variable impedance matcher. it will allow you to alter the output impedance and volume of a line level or larger signal so that you can then insert it into a guitar level input. an example would be to run a cable directly from your soundcard through the matcher and then straight into an effect pedal. the transformer used is of audio quality but it will impart a slight lofi "color" of its own

.\\\' CONTROLS .\\\\\\\\\\\\\\\\'

impedance knob: this will alter the output impedance from just over 9k to about 100ohm ( left knob )

volume knob: output volume control ( right knob)

input and output jacks: the input is marked with a small paint dot next to the jack ( mono / TS )

.\\\\\' DETAILS .\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\'

each one is handmade
extensively tested before shipping
case is spray painted and baked
aluminum enclosure - dimensions - 2.1 in. x 2.35 in.
graphics are imperfect spray painted stencils - clear coated for scratch resistance
input and output ¼” jacks ( mono / TS )
3 year warranty - covering both parts and labor

please feel free to contact me if you have any questions or visit the forum here

the first run
