bleak blink

passive low quality tilt switch

click image to view larger

sold out

'///. DESCRIPTION .\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\'

this is a simple tilt switch used for manual muting but this particular switch is of horrible quality, the little ball inside the switch itself used to make the connection isn't heavy enough, so the slightest nudge and it will sound like a shorting cable, though one that is pretty much the same every time. works with AC and DC. this is what happens when you switch part brands after prototyping with the intention of stepping up quality

.\\\\' CONTROL '///////////////////////////////////////////////////////.

motion: with the blink in the standard table sitting position the motion to cause muting is vertical

jacks: the input and output jacks are interchangeable

\\\\' NOTES '///////////////////////////////////

' on the blink '

i have a couple extra cases made so there will be another 5 of these at some point or they may be used for something else

all pcbs have been hand printed by alex of getlofi – designed, cut and drilled by me

\\\\' SAMPLES '////////

SAMPLE	some drums from paul birken. this file has the right channel clean so you can get an honest comparison

'/////////////////////////////////////////////.

each one is handmade
extensively tested before shipping
case spray painted - graphics imperfect spray painted stencils - poly coated and baked
dimensions: 3.45 in. x 1.4 in.
input and output ¼” jacks ( mono / TS )
3 year warranty - covering both parts and labor

please feel free to contact me if you have any questions or visit the forum here
